Dual Intensifer Pump Design With 2L Large Volume Accumulator. Eliminate The Fluctuation In The Cutting Process, And The Accumulator Is Integrally Forged.
1: Dual intensifier structure design, reducing failure rate
2: 6.5L/min large flow design, which can drive 1-4 robot armsat the same time
3: 60,000psi ultra-high pressure, ensuring production efficiency
4: Universal intensifier design reduces procurement difficulty
5: 2L large accumulator creates stable water jet
International universal intensifier, stable performance, good market universality
2L large flux accumulator to eliminate the fluctuation of water jet
Humanized control panel, easy to operate,
• PLC Based Controls
• Basic Control for Pump On/Off, E-Stop
• Hydraulic Shift
• Manual Cooling Water Valve (Oil/Water Heat Exchanger)
• Remote Start/Stop, E-Stop, Hi/Low Panel
• Intensifier Pump w/10 Micron Filter and Pressure Gauge
• Return Line Oil Filter with Service Indicator
• Dual Pressure Compensator Included
• Low Inlet Water Pressure Safety Switch (30psi)
• 60,000 psi Design Pressure
Brand | WINWIN | Model | WW60JET |
Attenuator capacity | 2L | Driving mode | High performance motor |
Voltage | 380V | Application | Water jet cutting system |
Rated power | 60HP | Maximum water flow | 6.5L/min |
Working pressure | 420Mpa | Continuous working pressure | 320Mpa-380Mpa |
Driving orifices Qty. | 1-4 | Temperature | 5-40°C |
Hydraulic oil type | No.46 anti-wear oil | Cooling method | Cool-heat exchanger |
Size (L * w * h) | 1.7m*1.1m*1.4m | Weight | 1.5T |
